P-010.xxH – P-025.xxH PICA Thru Ring Actuators

High-Load Piezo Actuators with Inner Hole

  • High load capacity
  • Extreme reliability: >109 cycles
  • Microsecond response
  • Subnanometer resolution
  • Large choice of designs
P-010.xxH – P-025.xxH PICA Thru Ring Actuators
Product Description Specifications Downloads Quote / Order

Stacked piezo linear actuator

Operating voltage 0 to 1000 V. Long lifetime without derating. High specific displacement. A mechanical preload can be attached via inner holes



Available options

  • SGS sensors for positional stability
  • PZT ceramic material
  • Operating voltage range, displacement, layer thickness
  • Load capacity, force generation
  • Geometric shapes: round, rectangular, various cross sections
  • Mechanical interface: flat
  • Integrated piezoelectric detector layers
  • Special high / low temperature versions
  • UHV-compatible versions up to 10-9 hPa
  • Non-magnetic versions
  • Extra-tight length tolerances



Fields of application

Industry and research. For optics, precision mechanics and machining, laser tuning
